8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer
8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer

8-year factory direct supply AH3-NA/B/C/D time relay 220V adjustable 24V power on delay timer

Get a Quote
  • Product Description

Product Description

Specification
Model
AH3-NA
AH3-NB
AH3-NC
AH3-ND
AH3-NE
Type
multi-range variable
Repeat accuracy
< 0.5%+20ms
Contact rating
AC 220V3A
Rated voltage
AC 380V AC 220V AC 110V; DC 24V DC 48V
Output contact
Form A/B
Time range
1s/1OS/1m/10m
3s/30s/3m/30m
6s/60s/6m/6m
1m/10m/1h/10h
3m/30m/3h/30h
Place of Origin
China
Brand Name
KECN/Neutral products、OEM
Model Number
AH3-NA/NB/NC/ND/NE
Usage
time delay
Size
Miniature
Protect Feature
Electromagnetic timing relay
Contact Load
Low Power
Number of contacts
Two sets of contacts
Contact capacitance
5A/250VAC
Contact form
one set of synchronous and one set of delayed
working modes
power on delay
power consumption
about 5VA
reset time
MAX 0.1 Sec
Voltage options
AC220V/DC24V
ambient temperature
-10℃+50℃
altitude
Less than 2000m
Product Description
d time relay 220v adjustable 24v power on delay timer186-1
d time relay 220v adjustable 24v power on delay timer186-2
d time relay 220v adjustable 24v power on delay timer186-3
d time relay 220v adjustable 24v power on delay timer186-4
d time relay 220v adjustable 24v power on delay timer186-5
d time relay 220v adjustable 24v power on delay timer186-6
Company Profile
We have been specializing in voltage protection devices for 8 years, Wenzhou Zhongzhe/Keqiang Electric. Since our employment, we have adhered to good quality and continuous research, which has been favored by a large number of customers. Therefore, we have created our own brand "KECN" and chose our advantages: 1. We can give you a good price to ensure you have a good profit 2. Good products, product quality assurance 3. Comfort after-sales service, we are online 24 hours a day! Waiting for your message.
d time relay 220v adjustable 24v power on delay timer186-7
d time relay 220v adjustable 24v power on delay timer186-8
d time relay 220v adjustable 24v power on delay timer186-9
d time relay 220v adjustable 24v power on delay timer186-10
d time relay 220v adjustable 24v power on delay timer186-11
d time relay 220v adjustable 24v power on delay timer186-12
FAQ
d time relay 220v adjustable 24v power on delay timer186-13
1. who are we?
Wenzhou KECN Electrical Technology Co., Ltd. is a high-tech enterprise specializing in the research and development,
manufacturing, and sales of electronic products. Its main products include various voltage protection devices and time relays,including switches and protectors. The company is in a leading position
2. Why did you choose us?
Only choose the right one, not the expensive one. Wenzhou KECN Electric Co., Ltd. provides you with high-quality products,
affordable prices, comfortable service, and ultimate after-sales service!
3.How do we ensure quality?
Always provide pre production samples before mass production; Always conduct final inspection before shipment;
4. What is the production capacity of your factory?
Our factory has an annual total production capacity of 5 million products. We have multiple production lines, each with a planned production capacity of 300 products per hour. The factory implements efficient production plans and resource allocation to improve capacity utilization and ensure customer satisfaction. We also maintain a certain level of flexible production capacity to cope with sudden demand. In addition, we continuously carry out process improvements and technological investments to enhance production capacity and efficiency, and have formulated capacity growth plans to adapt to future market demand growth.
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW,FCA；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
