10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty
10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty

10-year Manufacturer's Direct Supply of Foot and Palm Switches Two Year Warranty

Get a Quote
  • Product Description

Product Description

Products Description
product 10 year manufacturers direct supply of foot and palm switches two year warranty-1

Instructions for use

·Used for button switches or emergency stop switches·Used in harsh environmental conditions, such as dirt supermarkets ·Operated by hand tapping, foot stepping, or other body parts ·Can be rinsed with a high-pressure washer with a pressure of up to 100 Pa
product name
Foot clapper switch
colour
Multiple colors available
Operation type
Self reset
pull reset (self locking)
operating frequency
≤ 3600 times/h
≤ 600 times/h
contact arrangement
NO Normally Open/NC Normally Closed Optional
contact material
silver alloy
Switch capacity
ith:10A Ui:500V;AC-15 Ue:230V le:4A ；DC-13 Ue:24V le:1A or 10A 250VAC/30VDC
contact resistance
≤ 100m Ω initial value
protection grade
IP65
interface
3 * M20 side 1 * M16 bottom
dielectric withstand voltage
Charged body room: 1000VAC 50/60HZ time 1 minute

Between non charged bodies: 2500VAC 50/60HZ time 1 minute
insulation resistance
≥100mΩ@500VDC
ambient humidity
≤90%RH
ambient temperature
-25 ℃~+80 ℃ (storage -30 ℃~+120 ℃) without condensation
weight
Approximately 0.35KG
product 10 year manufacturers direct supply of foot and palm switches two year warranty-2
product 10 year manufacturers direct supply of foot and palm switches two year warranty-3
product 10 year manufacturers direct supply of foot and palm switches two year warranty-4
product 10 year manufacturers direct supply of foot and palm switches two year warranty-5
product 10 year manufacturers direct supply of foot and palm switches two year warranty-6
More Products
product 10 year manufacturers direct supply of foot and palm switches two year warranty-7
About Us
product 10 year manufacturers direct supply of foot and palm switches two year warranty-8
Certificate
product 10 year manufacturers direct supply of foot and palm switches two year warranty-9
Product Process
product 10 year manufacturers direct supply of foot and palm switches two year warranty-10
Transportation
product 10 year manufacturers direct supply of foot and palm switches two year warranty-11
FAQ
product 10 year manufacturers direct supply of foot and palm switches two year warranty-12
1. who are we?
We are based in Zhejiang, China, start from 2019,sell to North America(10.00%),South America(10.00%),Southeast
Asia(10.00%),Africa(10.00%),Mid East(10.00%),Central America(10.00%),South Asia(10.00%),Eastern Europe(5.00%),Eastern
Asia(5.00%),Northern Europe(5.00%),Domestic Market(5.00%),Western Europe(4.00%),Southern Europe(4.00%),Oceania(2.00%). There are
total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
VOLTAGE PROTECTOR,TIMER RELAY,MCB

4. why should you buy from us not from other suppliers?
Wenzhou KECN Electrical Technology Co., Ltd is a high-tech enterprise specialized in R&D, manufacturing, and sales of electronic
switches and protectors, the main products are all kinds of voltage protector and change-over. The company is in a leading posi

5. what services can we provide?
Accepted Delivery Terms: FOB,EXW,FCA；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
